Nemtek Druid LCD
POSMarket SKU: Z18026
This model is available in 2 different configurations. Select a configuration below or contact our experts on 1300 737 998.
Two-zone energizer monitors and controls high-voltage power on an electric fence
Product Overview
The LCD display in the Druid range makes information on the status and performance of the energizer quick and easy to read. Using the Adaptive Power Technology (APT) pioneered by Nemtek, these energizers offer a unique technology to detect how much power a fence can accept and handle before it starts to arc and waste energy. This maximises the power on the fence and minimises false alarms. Synchronisation between energizers can be achieved by using traditional network cabling or by the Druid synchronisation modules which use orbiting satellites and eliminate the need for cabling between the energizers.
- 28LCD – Two 3.7 Joule independently monitored and controlled zones
- 25LCD – Two 2.4 Joule independently monitored and controlled zones
- The robust and flexible design is ideal for residential, commercial, industrial and high-security sites
- Each zone can be set independently to be on/off or in high/low voltage modes
- Can be programmed into alarm sensor mode allowing it to be integrated into a separate burglar alarm system
- Four zones can easily be created by linking two Druid 28LCD energizers together using the Druid four-zone keypad
- Built-in alarm monitors tampering or faults on the high voltage and earth fence wires
- Connectable to armed response radio or GSM module
- Lightning and power surge protection
- Intelligent power saving to extend battery life
- Built-in gate alarm input to monitor if the gate is open or closed
- Optional keypad for controlling and programming the energizer. This allows the user to control the energizer remotely, with up to two keypads
- The relay expansion card can be used to increase the number of information outputs from the energizer
- Walk test mode for easy fence testing
- The LCD background colour changes to easily identify the fence condition
Product Specifications
| Druid 28LCD Energiser | |
| Physical | |
| Enclosure size | 400(L) x 270(W) x 125(D)mm |
| Weight | 5.7kg excluding battery (7AH) 8.0kg including battery (7AH) |
| IP rating | IPx4 |
| Operating temperature | -10°C to 50°C |
| Operating humidity | < 80% non-condensing |
| Electrical supply | |
| Electrical supply voltage | 240V |
| Typical power consumption | 18VA (normal operating conditions) |
| Standby Time | 24hrs (fully charged battery) |
| Internal battery | 7AH |
| Energy output | 3.7 Joule per zone (500 Ohms load) |
| High-voltage Output | |
| Energy output 500 Ohms load Druid 28LCD Energizer Druid 25LCD Energizer | 3.7 Joule per zone 2.4 Joule per zone (500 Ohms load) |
| Open circuit voltage | 9000V |
| Connections: Contact ratings maximum | |
| While relays have a higher rating, the manufacturer does not recommend an AC voltage of more than 50VAC | 10A @ 50VAC or 10A at 30DC (per relay) |
| Wiring lengths guide (live wires in a series circuit) for both solid and stranded Nemtek wires | |
| Galvanised 1.2mm - 1.6mm | 4km per zone |
| Galvanised 2.0mm | 4.5km per zone |
| Stainless steel 1.6mm (304 and 316) | Stainless steel 1.6mm (304 and 316) |
| Stainless steel 2.0mm (304 and 316) | 3.8km per zone |
| Aluminium alloy 1.6mm | 6km per zone |
| Aluminium alloy 2.0mm | 8km per zone |
| Aluminium alloy 2.5mm | 10km per zone |
