Axis C1310-E
$1,333.20 (incl. GST)
POSMarket SKU: Z15179
01796-001: C1310-E Network Horn Speaker, PoE, IO, 7 Watt, IP67
Axis' Outdoor network horn speaker for clear long-range speech
Product Overview
The Axis C1310-E/ AXIS-01796-001 Network Horn Speaker is designed to provide clear and understandable voice messages or live speech. This rugged horn speaker is perfect for most outdoor environments in most climates.
The C1310-E is an all-in-one unit with built-in power amplifier and signal processing (DSP). Pre-configured digital signal processing produces clear, understandable voice every time. Onboard memory supports pre-recorded voice messages. Or, security personal can respond to notifications or provide instructions with live speak. AXIS C1310-E also has a built-in microphone for remote health testing – so you always know it’s working. This network speaker plugs right into standard IP networks. It supports Power over Ethernet (PoE), so a single cable provides both power and connectivity. Because it’s a stand-alone unit, you can place it anywhere. And it’s based on open standards, for easy integration with your video management software (VMS), with Voice over IP (VoIP) telephony (using SIP), and with analytics from Axis and our partners, Audio Manager Edge application is pre-installed on AXIS C1310-E.
Ever struggled to understand voice coming over a loudspeaker? Those days are over with AXIS C1310-E, this speaker delivers clear speech you can really hear even when it’s coming from a long way away. Network audio technology and the built-in preconfigured digital signal processor (DSP) in every speaker ensure it. Whether you choose to use remote audio with pre-recorded event-triggered messages or let your security personnel respond with live speech in response to an alert.
Thanks to the built-in microphone, AXIS C1310-E also supports two-way communication allowing you to get an immediate response from the people involved such as acknowledgement of your instructions, providing more info when needed, etc. The microphone can also be used for remote health testing of the speaker, so you know it’s working.
FEATURES
The C1310-E is an all-in-one unit with built-in power amplifier and signal processing (DSP). Pre-configured digital signal processing produces clear, understandable voice every time. Onboard memory supports pre-recorded voice messages. Or, security personal can respond to notifications or provide instructions with live speak. AXIS C1310-E also has a built-in microphone for remote health testing – so you always know it’s working. This network speaker plugs right into standard IP networks. It supports Power over Ethernet (PoE), so a single cable provides both power and connectivity. Because it’s a stand-alone unit, you can place it anywhere. And it’s based on open standards, for easy integration with your video management software (VMS), with Voice over IP (VoIP) telephony (using SIP), and with analytics from Axis and our partners, Audio Manager Edge application is pre-installed on AXIS C1310-E.
Ever struggled to understand voice coming over a loudspeaker? Those days are over with AXIS C1310-E, this speaker delivers clear speech you can really hear even when it’s coming from a long way away. Network audio technology and the built-in preconfigured digital signal processor (DSP) in every speaker ensure it. Whether you choose to use remote audio with pre-recorded event-triggered messages or let your security personnel respond with live speech in response to an alert.
Thanks to the built-in microphone, AXIS C1310-E also supports two-way communication allowing you to get an immediate response from the people involved such as acknowledgement of your instructions, providing more info when needed, etc. The microphone can also be used for remote health testing of the speaker, so you know it’s working.
FEATURES
- All-in-one speaker system
- Connects to standard network
- Simple installation with PoE
- Remote health testing
- Two input/outputs (GPIO)
Product Specifications
| C1310-E Network Horn Speaker | |
| Audio | |
| Audio Streaming | One-Way/Two-Way (Mono) |
| Audio Encoding | AAC LC 8/16/32/48 kHz, G.711 PCM 8 kHz, G.726 ADPCM 8 kHz, Axis µ-law 16 kHz, WAV, MP3 in Mono/Stereo from 64 to 320 kb/s CBR and VBR Sampling Rate from 8 to 48 kHz |
| Audio Input/Output | Built-In Microphone (Can be Disabled Mechanically) Microphone Specification: 50 Hz to 12 kHz |
| Speaker | |
| Max SPL | >121 dB |
| Frequency Response | 280 Hz to 12.5 kHz |
| Coverage Pattern | 70° Horizontal by 100°Vertical (at 2 kHz) |
| Amplifier | |
| Type | Built-In 7 W Class D Amplifier |
| Network | |
| Security | Password Protection, IP Address Filtering, HTTPS Encryption, IEEE 802.1X Network Access Control, Digest Authentication, User Access Log |
| Protocols | IPv4/v6, HTTP, HTTPS, SIP, SSL/TLS, QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnPTM, SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, TCP, UDP, IGMPv1/v2/v3, ICMP, DHCP, ARP, SOCKS, SSH |
| System Integration | |
| API | Open API for Software Integration, including VAPIX, AXIS Video Hosting System (AVHS) with One-Click Connection, AXIS Camera Application Platform (ACAP) |
| Synchronization | Built-In Audio Synchronization for up to 50 Speakers with Unicast and Hundreds of Speakers with Multicast |
| VoIP | Support for Session Initiation Protocol (SIP) for Integration with VoIP Systems, P2P or Integrated with SIP/PBX |
| Audio | Intelligent Audio: Auto Speaker Test |
| Event Triggers | Virtual Inputs, External Input Call: DTMF, State Changes, AXIS Camera Application Platform (ACAP) |
| Event Actions | File Upload: HTTP, Network Share & Email Notification: Email, HTTP & TCP Play Audio Clip Perform Auto Speaker Test Send SNMP Trap Status LED |
| Built-In Installation Aids | Test Tone Verification and Identification |
| Monitoring | Functional Monitoring: Auto Speaker Test, Connection Verification, Built-In System Logging |
| General | |
| Casing | Impact-Resistant Aluminum, IP66-, IP67-, NEMA 4X-Rated, and MIL-STD-810G 509.5-Rated |
| Memory | 256 MB RAM, 512 MB Flash |
| Power | PoE IEEE 802.3af/at Type 1 Class 3 (Maximum 12.95 W) |
| Connectors | 1 x 100M RJ45 I/O: 4-Pin 2.5 mm Terminal Block for 1 Input & 1 Output |
| VMS Software | AXIS Camera Station, VMS from Axis' Application Development Partners |
| Languages | English, German, French, Spanish, Italian |
| Operating Conditions | -40 °F to 140°F / -40°C to 60°C Humidity: 10-100% RH (Condensing) |
| Dimensions | Without Bracket: 6.5 x 8.8 x 9.8" / 164 x 225 x 250 mm With Bracket: 6.5 x 8.8 x 12" / 164 x 225 x 305 mm |
| Weight | 2.3 lb / 1.9 kg |
