Hanwha QNP-6230RH
$1,306.25 (incl. GST)
POSMarket SKU: Z14633
QNP-6230RH: Hanwha Wisenet 2MP PTZ Camera, H.265, WDR, 100m IR, IP66, IK10, 4.44 - 102.2mm
Hanwha Wisenet 2MP PTZ Camera, WDR, 100m IR
Product Overview
Monitor an indoor or outdoor area with the QNP-6230RH 2MP PTZ Network Camera from Hikvision. This unit uses a 1/2.8" CMOS sensor to capture 1920 x 1080 resolution video at 30 fps. IR LEDs provide up to 328' of night vision. A 4.44-102.2mm varifocal lens delivers a 61.8 to 3.08° horizontal field of view. This camera features endless panning, a -5 to 90° tilt range, and 23x optical zoom. A built-in memory card slot accepts microSD/SDHC/SDXC cards up to 256GB (available separately). Two-way audio is possible thanks to an audio input and output. Integrated PoE technology simplifies connectivity by transferring data and power over one cable.
This NDAA-compliant PTZ camera complies with ONVIF profiles G, S, and T, making it compatible with a wide range of surveillance devices. It is housed in an IP66- and IK10-rated enclosure that is suitable for safe outdoor use in areas at risk of vandalism.
FEATURES
This NDAA-compliant PTZ camera complies with ONVIF profiles G, S, and T, making it compatible with a wide range of surveillance devices. It is housed in an IP66- and IK10-rated enclosure that is suitable for safe outdoor use in areas at risk of vandalism.
FEATURES
- Max. 2megapixel (1920 x 1080) resolution
- 4.44~102.2mm(23x) lens
- Max. IR viewable length : 100m
- Day&night(ICR), WDR(120dB), DIS(Built-in gyro sensor)
- Intelligenct Analytics
- Multiple streaming, WiseStream II support
- H.265, H.264, MJPEG codec support
- MicroSD / SDHC / SDXC memory
- IP66, IK10
Product Specifications
| Video | |
| Imaging Device | 1/2.8" 2MP CMOS |
| Effective Pixels 1 | 944(H) x1212 (V) |
| Min. Illumination | Color: 0.05Lux (F1.6, 1/30sec) BW: 0Lux(IR LED On) |
| Video Out | CVBS: 1.0 Vp-p / 75Ω composite, 720x480(N), 720x576(P) for installation |
| Lens | |
| Focal Length (Zoom Ratio) | 4.44~102.2mm (23x) zoom |
| Max. Aperture Ratio | F1.6 (Wide) ~F3.6 (Tele) |
| Angular Field of View | H: 61.8° (Wide) ~3.08° (Tele) / V: 36.2°(Wide)~1.73°(Tele) |
| Min. Object Distance | Wide: 1.5m (4.92ft), Tele: 2m (6.56ft) |
| Focus Control | Oneshot AF |
| Lens Type | DC auto iris |
| Pan / Tilt / Rotate | |
| Pan Range | 360Ëš Endless Pan Speed Preset: 400Ëš/sec, Manual: 0.024Ëš/sec~250Ëš/sec |
| Tilt Range | 95Ëš(-5Ëš~90Ëš) Tilt Speed Preset: 250Ëš/sec, Manual: 0.024Ëš/sec~250Ëš/sec Sequence Preset(300ea), Swing, Group(6ea), Trace, Tour, Auto Run, Schedule |
| Preset Accuracy | ±0.2Ëš |
| Azimuth | Support |
| Operational | |
| IR Viewable Length | 100m (328.08ft) |
| Camera Title Displayed | up to 85 characters |
| Day & Night | Auto (ICR) |
| Backlight Compensation | BLC, HLC, WDR, SSDR |
| Wide Dynamic Range | 120dB |
| Digital Noise Reduction | SSNRâ…¤ |
| Digital Image Stabilization | Support (built-in gyro sensor) |
| Defog | Support |
| Motion Detection | 8ea, 8point polygonal zones |
| Privacy Masking | 24ea, rectangular Support - Color: Grey/Green/Red/Blue/Black/White - Mosaic |
| Gain Control | Low / Middle / High |
| White Balance | ATW / AWC / Manual / Indoor / Outdoor |
| Electronic Shutter Speed | Minimum / Maximum / Anti flicker (2~1/12,000sec) |
| Video Rotation | Flip, Mirror |
| Analytics | Directional detection, Motion detection, Enter/Exit, Tampering, Virtual line |
| Serial Interface | RS-485(Samsung-T, Pelco-D/P, Panasonic, Bosch, AD, GE, Vicon, Honeywell) |
| Alarm | I/O Input 4ea / Output 2ea |
| Alarm Triggers | Analytics, Network disconnect, Alarm input |
| Alarm Events | File upload via FTP and e-mail Notification via e-mail SD/SDHC/SDXC or NAS recording at event triggers Alarm output PTZ Preset |
| Audio In | Selectable (mic in/line in) |
| Supply voltage: | 2.5VDC (4mA), Input impedance: 2K Ohm |
| Audio Out | Line out, Max.output level: 1Vrms |
