Hikvision DS-2DT6223-AELY
POSMarket SKU: Z14177
DS-2DT6223-AELY: 2MP Outdoor Anti Corrosion PTZ Camera, 23x Zoom, WDR, NEMA 4X, HiPoE
2MP 6-inch 23x Anti-corrosion Network Speed Dome
Product Overview
Features
- 316L stainless steel enclosure, protecting cameras to be used in corrosive environments, providing reliability and longevity compared to standard cameras
- A built-in heater allows for start-up in ultra-low temperatures to -40°
- IP67/IK10: water resistant and vandal proof, preventing water ingress for outdoor use
- DarkFighter technology enables the capture of high quality color images in even the dimmest lighting environments
- PTZ: pan-tilt-zoom ability allows the camera to move to view zones of interest
- Up to 23X zoom: zoom to examine subjects of interest within expansive scenes
Product Specifications
| CAMERA MODULE | |
| Image Sensor | 1/1.9" Progressive Scan CMOS |
| Min. Illumination Color: | 0.002 Lux @ (F1.5, AGC ON), B/W: 0.0002Lux @ (F1.5, AGC ON) |
| Max. Image Resolution | 1920 s 1080 |
| Focal Length | 5.9 to 135.7 mm, 23x |
| Digital Zoom | 16x |
| Zoom Speed | Approx. 4.4s (Optical Wide-Tele) |
| Field of View | 59.8°to 3.0°(Wide-Tele) |
| Working Distance | 10 to 1500 mm (Wide-Tele) |
| Aperture Range | F1.5 to F3.4 |
| Focus Mode | Auto/Semi-Auto/Manual |
| WDR | 120 dB |
| S/N Ratio | ≥ 55dB |
| Shutter Time | 50Hz: 1 to 1/30,000s; 60Hz: 1 to 1/30,000s |
| AGC | Auto/Manual |
| White Balance | Auto/Manual/ATW/Indoor/Outdoor/Daylight lamp/Sodium lamp |
| Day & Night | IR Cut Filter |
| Privacy Mask | 24 programmable privacy masks; optional multiple colors and mosaics |
| Enhancement | 3D DNR, EIS, Defog, HLC/BLC, SVC |
| SYSTEM INTEGRATION | |
| Application Programming | Open-ended API, supports ONVIF, PSIA , CGI and Genetec |
| Web Browser | IE 7+, Chrome 18 +, Firefox 5.0 +, Safari 5.02 +, supports multi-language |
| RS-485 Protocols | HIKVISION, Pelco-P, Pelco-D, self-adaptive |
| Power | Hi-PoE & 24 VAC, Max.60W |
| Working Temperature | -40°C to 65°C (-40°F to 149°F) |
| Humidity 9 | 0% or less |
| Anti-Corrosion Standard | C5-M, NEMA 4X |
| Protection Level | IP67, IK10, TVS 4,000V lightning protection, surge protection and voltage transient protection |
| Certification | FCC, CE, UL, RoHS, IEC/EN 61000, IEC/EN 55022, IEC/EN 55024, IEC /EN60950-1 |
| Dimensions | Φ262 mm × 330 mm (Φ10.3" × 13.0") |
| Weight (approx.) | Approx.: 10 kg (22 lb.) |
| Pan and tilt | |
| Range | Pan:360° endless; Tilt: -20°to 90°(auto flip) |
| SPEED | |
| Pan Manual Speed: | 0.1°to 300°/s, Pan Preset Speed: 540°/s |
| Tilt Manual Speed: | 0.1°to 240°/s, Tilt Preset Speed: 400°/s |
| Preset No. | 300 |
| Patrol | 8 patrols, up to 32 presets per patrol |
| Pattern | 4 patterns, with the recording time not less than 10 minutes per pattern |
| Park Action | Preset/Patrol/Pattern/Auto scan/Tilt scan/Random scan/Frame scan/Panorama scan |
| Scheduled Task | Preset/Patrol/Pattern/Auto scan/Tilt scan/Random scan/Frame scan/Panorama scan/Dome reboot/Dome adjust/Aux output |
