Axis DS-6900UDI

from $1,194.46 (incl. GST)

POSMarket SKU: Z15241

This model is available in 3 different configurations. Select a configuration below or contact our experts on 1300 737 998.

DS-6900UDI Series Decoders support resolutions of up to 4K (3,840 x 2,160 @ 30 Hz) via HDMI output interfaces.

Product Overview

Designed for the high-definition video monitoring system, the Hikvision DS-6900UDI Series Decoder is developed on the basis of embedded hardware platform, ensuring high reliability and stability of system running. This decoder series is provides simultaneous decoding, and outputting decoded video via BNC, VGA, or HDMI interfaces, and it also supports multiple video stream formats like H.265, H.264+, H.264 and MPEG4. The decoded video can be displayed on a video wall or large screen.

FEATURES
  • HDMI, VGA, and BNC output interfaces
  • Up to 4K (3840 x 2160@30Hz) via HDMI output interfaces (only for even interface)
  • Up to 2-ch@12MP, 4-ch@8MP, 6- ch@5MP, 10-ch@3MP or 16-ch@2MP; Up to 4-ch@12MP, 8-ch@8MP, 12- ch@5MP, 20-ch@3MP or 32-ch@2MP; Up to 8-ch@12MP, 16-ch@8MP, 24- ch@5MP, 40-ch@3MP and 80-ch@2MP
  • H.265+/H.265, H.264+/H.264, MPEG4 and MJPEG video compression
  • Supports multi-screen control when PC installed with RSC server
  • Flexible display configuration options

Product Specifications

DS-6900UDI Series
Decorder
VGA And Dvi-I Input WSXGA:1690×1050/60Hz
WXGA:1440×900/60Hz
WXGA:1280×800/60Hz,1366×768/60Hz
1080P:1920×1080@50/60Hz
UXGA:1600×1200@60Hz
XVGA:1280×960@60Hz
720p:1280×720@50Hz/60Hz
SXGA:1280×1024@60Hz
XGA:1024×768@60Hz
BNC Output 8-ch,2 DB 15
HDMI Output 4K:3840×2160@30Hz(for odd interface only)
1080p:1920×1080@50/60Hz
WSXGA:1680×1050/60Hz
UXGA:1600×1200@60Hz(for odd interface only)
720p:1280×720@50Hz/60Hz
SXGA:1280×1024@60Hz
XGA:1024×768@60Hz
Decoding Resolution Up to 12MP
Decoding Channel 128-ch
Decoding Capability 12MP@20fps:16-ch
8MP@30fps:32-ch
5MP@30fps:48-ch
3MP@30fps:80-ch
1080p@30fps/3Mbps:128-ch
Split Screen 1/4/6/8/9/12/25/36
Network Interface 2,10/100/1000 Mbps self-adaptive management network interface
2,10/100/1000 Mbps self-adaptive Ethernet interface
16,10M/100 Mbps self-adaptive Ethernet interface
Two-Way Audio In 1-ch,3.5 mm connector(2.0 Vp-p,1kΩ)
Serial Interface 1 RS-232(RJ45),1 RS-485
Power Consumption ≤ 108W
Dimensions(W*D*H) 440×311×80 mm (17.32×12.24×3.15 inch)
Two-Way Audio Out 1-ch,3.5 mm connector(2.0 Vp-p,1kΩ)
Audio Output 16-ch,2 DB 15
Alarm Out 8-ch
Alarm Input 8
Power Supply 100 to 240 VAC
Working Temperature -10°C to +55°C（14°F to 131°F）
Working Humidity 10% to 90%
≤ 6.4 kg（14.11 lb）
