Axis F41
POSMarket SKU: Z14914
0658-001: F41 Main Unit to suit F Series Sensor Units, 1080p, H.264, Zipstream, PoE, WDR
Axis' main unit to suit F Series Sensor Units, featuring rugged design with WDR and HDTV 1080p.
Product Overview
With Axis F41 WDR Forensic Capture which can be activated when the main unit is connected to an AXIS F Sensor Unit that supports this feature. The Axis’ WDR - Forensic Capture enables a high level of detail to be visible in both bright and dark areas of a scene - an important consideration in surveillance applications that are ideally suited for scenarios such as at entrances or in front of ATMs where the subject may be dark against a bright background, or in nighttime situations where the camera must handle low-light environments together with bright lights from vehicles, street lamps, signage and stores.
Together with an Axis F Sensor Unit, this can give you color video in light as low as 0.3 lux.
FEATURES
- HDTV 1080p at 50/60 frames per second
- WDR - Forensic Capture
- Axis' Zipstream technology
- Rugged, easy-to-install design
- Two-way audio
- Input/output ports for external devices
- Full-sized SD card slot
- Power over Ethernet or DC power
Product Specifications
| Axis Communications F41 Specs | |
| Resolution | 1920 x 1200 to 160 x 90 |
| Frame Rate | H.264: 2 streams in 1920x1080 at 30fps 1 stream in 1920x1080 at 60 fps Motion JPEG:2 streams in 1920x1080 at 30fps 1 stream in 1920x1080 at 30 fps |
| Compression | Video: H.264 (MPEG-4 Part 10/AVC) Baseline, Main and High profiles Motion JPEG Audio: AAC 8/16/32 kHz, 8-128 kbit/s AAC LC 8/16/32 kHz, 8-128 kbit/s G.711 PCM 8 kHz 64 kbit/s G.726 ADPCM 8 kHz 32 kbit/s or 24 kbit/s Configurable bit rate |
| Audio | 1 x 3.5 mm mic/line in 1 x 3.5 mm line out |
| Alarm Connectors | 6-pin Terminal block for 4 configurable inputs/outputs (12 V DC output, max. load 50 mA) |
| Connectors | 1 x RJ12 connector for the sensor units 5-pin terminal block RS232 |
| Network Connection | Female RJ45 10 BASE-T/100 BASE-TX PoE |
| Supported Protocols | IPv4/v6, HTTP, HTTPS, SSL/TLS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, CIFS/SMB, SSH. This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit, and cryptographic software written by Eric Young |
| Memory | 512 MB RAM, 256 MB Flash |
| Memory Card | 1 x SD/HC/XC card slot, supports up to 64 GB |
| Power | Power over Ethernet (PoE) IEEE 802.3af/802.3at Type 1 Class 3, max 7.7 W 8 - 28 VDC, max 7.8 W |
| Environmental | Operating temperature: -22 to 140°F (-30 to 60°C) Storage temperature: -40 to 149°F (-40 to 65°C) Humidity: 10 to 85%,non-condensing |
| Dimensions | 4.1 x 3.0 x 1.1" (10.3 x 7.6 x 3.1 cm) |
| Weight | 1.2 lb (520 g) |
